V2 Simple SC14 Supercharger Brackets for BMW’s

  • Beitrags-Autor:
  • Lesedauer:2 min Lesezeit

The V2 Evolution of the our Original SC14 Supercharger Brackets for BMW’s are available now. Unlike the V1, These V2 design requires no welding at all. Its a simple Thick Plate Based Bolt on Bracket System that now truly offers an simple universal fitment of the SC14 Supercharger into all BMW 6 Cylinder M50NV/M52/M54/S50/S52/S54 Based Motors.

The HMW V2 Design Replaces the Power Steering Bracket as a whole as well as cleverly comes around the alternator and bmw belt tensioner to secure itself onto the motor, On top of that there is the addition of top brackets to offer more rigidness to the setup.

Update: 20th Oct 2016 – V2.1 Revisions Available Now!

Economical & Elegant
WeiterlesenV2 Simple SC14 Supercharger Brackets for BMW’s

V2 SC Belt Orientation Wrap Pulley Addon Upgrade for V1 Users

  • Beitrags-Autor:
  • Lesedauer:1 min Lesezeit

For users of the V1 Design, a Minor Evolution of the Bracket System, This adds a secondary pulley and changes the belt orientation slightly, allow more tension to be put on as well as allow more belt grip and wrap around the SC and alternator pulleys, specially needed when using smaller pulleys to eliminate any belt slip, this should also increase the boost due to the factors above.

Belt Routing
V1 to V2 Wrap Pulley Addon Plate

Image on the right is full scale copy of the template itself, which can be printed out to borderless A4 Paper, mind the dimensions.

WeiterlesenV2 SC Belt Orientation Wrap Pulley Addon Upgrade for V1 Users

HMW M52 Prototype Supercharged BMW Setup in Action!!

  • Beitrags-Autor:
  • Lesedauer:1 min Lesezeit

The much awaited HMW M52 Prototype Demonstration video, SC14 Roots Supercharged BMW Driving around Northland, New Zealand, To show case just how reliable and solid my DIY Supercharged Budget setup is even without any tunes.

4 PSI 103mm Pulley, #21.5 Stock Injectors, Stock DME, Stock MAF, M50 Manifold, No Tune.

Music – Black Sabbath song ‘Iron Man’, Instrumental variation performed by Deano Silk Music. Enjoy 🙂

WeiterlesenHMW M52 Prototype Supercharged BMW Setup in Action!!
