W.M.D. 45 Supercharger Kit

W.M.D. 45 SUPERCHARGER KIT

The W.M.D. 45 stands for Werner Mayerhofer Designs. Originally designed in Ireland between 2021 – 2022,  this Supercharger Kit is designed to be used on the BMW 4 Cylinder M44 Engine with support for the M42 and M43. With full air to air intercooling support, this kit is capable of pushing the stock engine to its safe limits.

This setup comes with its own custom crank pulley, tensioner and independent belt drive which allows you to preserve all the original stock belt driven engine accessories as the alternator, power steering, air conditioner, all in their original position.

Umfasst:

• Kompletter Satz Halterungen
• Supercharger Discharge Pan with Inlet and Outlet manifolds for the M45 Supercharger
• Custom Drive Pulley (Replaces Power Steering pulley)
• Gates T38311 Belt Tensioner System with Independent Belt Drive (Included with orders from summer 2024 onwards)

• Umlenkrollen
• Proper Gaskets – (Included with orders from fall 2024 onwards)

• Kompletter Satz Befestigungselemente (Muttern, Schrauben und Abstandshalter)
• Finished in Powder Coated Raceway Red colour (Supercharger Kit)

• Gewährleistung von 36 Monaten auf die Verarbeitung**

Supported BMW models & cars due to using 4-cylinder BMW M42, M43 & M44 engines:

• 1989–1991 E30 318is

• 1990–1992 E30 318i

• 1992–1995 E36 318i

• 1991–1995 E36 318is

• 1994–1995 E36 318ti

• 1996-2000 E36 318i, 318is and 318ti

• 1996-1999 Z3 1.9

• 1992-1998 E36 318i

• 1994-1996 E34 518i

• 1995-1996 E34 518g Touring

• 1995-2001 Z3 1.8

• 1999-2001 E36 316i Compact

• 1999-2002 E46 316i

• 1998-2001 E46 318i/318Ci

• 1999 -2002 Z3 1.9

Anmerkungen

• The Supercharger is not included in the kit and you are advised to use the given part number for the supercharger and order the supercharger locally.
• Stock M45 pulley will limit the boost to 8PSI with an air to air intercooler, For 12+ PSI you will have to rebuild the M45 Supercharger with new bearings and use any available Hyde Motor Works Overdrive Riemenscheibe, verwenden made for the M45 Supercharger.
• On the older M42/M43 Engines with the V Belt drive system, you must upgrade to the newer Micro V belt system from the newer M42/M43/M44 engines. Having the M44 Manifold is recommended for best fitment.
• Currently the kit supports only the Eaton M45 Supercharger, future support will be added for the Eaton M62. *

Um die Installation eines der Setups abzuschließen, benötigen Sie außerdem die folgenden zusätzlichen Teile:

• Eaton M45 Supercharger (Mercedes variant only, check the technical specifications for part numbers)

• ein Ladeluftkühler-Kit mit Silikonrohren und Schlauchschellen (kann separat erworben werden)

• Unterdruckschlauch

• einen Luftfilter mit hohem Durchsatz

• eine Ladedruckanzeige

• ein Umgehungsventil mit Rückführung und

• das passende Tuning

Bitte konsultieren Sie die Installationsanleitung für weitere Informationen.

Für das Tuningempfehlen wir die Verwendung einer unserer ausgewählten Tuning Partner.
In unserem Shop können Tuning-Pakete auch erworben werden.

Bitte informieren Sie sich im Produkt Finder über alle in unserem Shop verfügbaren Teile, die für diesen Aufbau erforderlich sind.
For more information on the W.M.D. 45 Supercharger Kit please check the overview on PRODUKTE Seiten.
